Choose the proper material for your application
QUALYFAN helps you find the right fan!
HW Ventilation Kanban service
HW Ventilation offers the best axial fans, made of the top-quality materials.
Different working conditions, and different environments in which our fans can be employed, require combinations of materials to suit various operating temperatures, humidity levels, revolutions per minute.
HasconWing® axial impellers are available in several different materials and colors:
HW Ventilation offers the best axial fans, made of the top-quality materials.Different working conditions, and different environments in which our fans can be employed, require combinations of materials to suit various operating temperatures, humidity levels, revolutions per minute. HasconWing® axial impellers are available in several different materials and colors: PP, Polypropylene PPG, Polypropylene Glass Reinforced (Polypropylene reinforced with 30% glass) PAG, Polyamide Glass Reinforced (PA6) PAS, Polyamide Glass Reinforced (PA6) ALU, Aluminum RYT, Ryton PVDF, Foraflon
We also provide impellers made of materials which are compliant with the ATEX directive, and that are thought for applications in potentially explosive environments:
On May 31 2017, HW Ventilation received by TÜV Rheinland the Certificate of Deposit of Documentation in compliance with the ATEX Directive 2014/34/EU for the MAV series of axial ventilators.
Our customers are at the center of our activities and we are always delighted to help them to find the right material for their applications.
| Material | Description | Color | Applications | Op. temperature |
|---|---|---|---|---|
| PP | Polypropylene (PP) | Yellow | TS |
From -10° to +85°C |
| PPG | Glass Reinforced Polypropylene (PP 30% glass) | Orange | TS, TM, SR, Q, A, C, F |
From -20° to +90°C |
| PAG | Glass Reinfoced Polyamide (PA6) | White | TS, TM, SR, Q, A, C, F | From -40° to +120°C |
| PAS | Glass Reinforced Polyamide (PA6) | Nero | SR | From -40° to +120°C |
| ALU | Aluminum | R, C-ALU, De-ALU | From -50° to +250°C | |
| RYT | Ryton | Brown | TS, TM, Q | From -20°C to +140°C |
| PAA | Antistatic Polyamide | Black | TS, TM, Q, A | From -20° to +110°C |
| PAX | Antistatic, Self extinguishing PA | Black | TS, TM, Q, A | From -20° to +110°C |
| PAM | Antistatic, Self extinguishing, Magnetically shielded PA | Black | TS, TM, Q, A | From -20° to +110°C |
| PAT | Glass Reinforced Polyamide for Railway Applications* | Black | TS |
From -40° to +120°C |
* PAT is a special glass reinfoced polyamide, that is certified against the main international standards of fire resistance and smoke opacity - EN 45545, NF F16-101/102, NFPA 130
We also provide impellers made of materials which are compliant with the ATEX directive, and that are thought for applications in potentially explosive environments: PAA, Antistatic Polyamide PAX, Antistatic, Self extinguishing PA PAM, Antistatic, Self extinguishing, Magnetically shielded PA PAT, Polyamide Glass Reinforced (PA66) for railway applications On May 31 2017, HW Ventilation received by TÜV Rheinland the Certificate of Deposit of Documentation in compliance with the ATEX Directive 2014/34/EU for the MAV series of axial ventilators. Our customers are at the center of our activities and we are always delighted to help them to find the right material for their applications. MaterialDescriptionColorApplicationsOp. temperature PP Polypropylene (PP) Yellow TS From -10° to +85°C PPG Glass Reinforced Polypropylene (PP 30% glass) Orange TS, TM, SR, Q, A, C, F From -20° to +90°C PAG Glass Reinfoced Polyamide (PA6) White TS, TM, SR, Q, A, C, F From -40° to +120°C PAS Glass Reinforced Polyamide (PA6) Nero SR From -40° to +120°C ALU Aluminum R, C-ALU, De-ALU From -50° to +250°C RYT Ryton Brown TS, TM, Q From -20°C to +140°C PAA Antistatic Polyamide Black TS, TM, Q, A From -20° to +110°C PAX Antistatic, Self extinguishing PA Black TS, TM, Q, A From -20° to +110°C PAM Antistatic, Self extinguishing, Magnetically shielded PA Black TS, TM, Q, A From -20° to +110°C PAT Glass Reinforced Polyamide for Railway Applications* Black TS From -40° to +120°C * PAT is a special glass reinfoced polyamide, that is certified against the main international standards of fire resistance and smoke opacity - EN 45545, NF F16-101/102, NFPA 130
